New CALB L160F100 3.2V 100Ah LiFePO4 Battery Cell

» lifepo4 prismatic cells » New CALB L160F100 3.2V 100Ah LiFePO4 Battery Cell
  • New CALB L160F100 3.2V 100Ah LiFePO4 Battery Cell

    lifepo4 prismatic cells

    CE, UL, MSDS, and UN38.3 have been approved.(CALB L160F100)3.2V 100Ah Lithium Iron Phosphate(LiFePO4) battery cells were already passed all of the safety tests(overcharge, over-discharge, over-temperature, short circuit, drop, crush, needle puncture tests, etc). These battery cells do not catch fire, no explosion, and no leakage.

    • Specifications

    New CALB L160F100 3.2V 100Ah LiFePO4 Battery Cell

    CALB L160F100 3.2V 100Ah –This battery is CALB’s latest aluminum-cased power lithium iron phosphate prismatic battery, which is especially suitable for power applications, such as electric cars, electric buses, mini electric vehicles, golf carts, etc. We have deep cooperation with CALB and can offer the best price.

    The approximate delivery time is as follows.

    0-100 pcs: in stock

    100-2000 pcs: 5-7 days

    2000-10000pcs: 15-20 days


    Battery Cell TypeLithium Iron Phosphate (LiFePO4) battery cells
    Model NumberCALB L160F100
    Nominal Voltage3.2V
    Nominal Capacity100Ah
    Cycle Life>3500 cycles
    Working Voltage2.5-3.65V
    Internal Resistance0.2~0.5mΩ
    End of discharge Voltage2.5V
    Charge MethodCC/CV
    Max.Continuous discharge current100A
    Max (Long)Pulse Discharge Current200A Maximum duration:3min
    Max. (Short)Pulse Discharge Current300A
    Dimensions(mm)160mm x 49.9mm x 118.5mm
    Shell MaterialAluminum

    Cell Dimensions

    • A Grade, New, with all test report
    • Highly safe, no fires, no explosions.
    • High Power Performance
    • High Energy Density
    • High Gravimetric and Volumetric Power Density.
    • Longer Cycle life

    Mini EV, Electric Vehicle, Electric Bus, Mini Electric Vehicles, Golf cart, Solar street light, Forklift, UPS, yacht, AGV (Automated Guided Vehicle), RV( Recreational Vehicle), Energy storage system(ESS) for wind and solar power, Household storage system and etc.
